Bucket 40cm suitable for JCB 8025/803/8035 mini excavator - LJ80340
HIMACORE

Bucket 40cm suitable for JCB 8025/803/8035, 1CX mini excavators

Catalog number:SKX825215HM Nr OEM:980/90470 Manufacturer:HIMACORE
Add a review

Excavator Bucket 40cm suitable for JCB 8025 1CX - 980/90470

Technical Specification and Compatibility

Excavator bucket with a width of 40 cm (400 mm) and part number 980/90470, manufactured by HIMACORE. It is a reinforced attachment dedicated to JCB mini excavators in the 2.5 – 3.5 ton weight range (8025-8035 series) and compact 1CX backhoe loaders. The bucket has a capacity of 68 liters and is equipped with additional protection systems to increase its durability in difficult conditions.

Part Number: 980/90470
Component Type: Excavator Bucket 400mm
Width: 400 mm (40 cm)
Capacity: 68 Liters (0.068 m³)
Pin Diameter: 35 mm
Dipper Width: 135 mm
Pin Spacing (C-C): 130 mm
Manufacturer: HIMACORE

HIMACORE equipment is distinguished by the use of high-quality materials. The body is made of 5 mm thick sheet metal, and the blade is made of low-alloy S355 steel with increased strength, which guarantees a long service life under intensive use.

Features of HIMACORE 980/90470 Bucket

Reinforcement Package: The bucket has additional side cutters, reinforcing strips on the bottom, and side guards, which protects the structure from abrasion and deformation.
Perfect Dimensions: 130 mm pin spacing and 35 mm diameter are standard for JCB 8025/8030/1CX machines, ensuring a perfect fit without play.
S355 Blade: The use of higher strength steel on the cutting edge ensures resistance to impact and abrasion in stony ground.
Complete Set: The bucket is equipped with teeth and bushings, ready for mounting on a quick coupler or directly on pins.

Application in JCB machinery

Machine Group Models
Mini Excavators (2.5 - 3.5t) 8025, 8026 CTS, 8027, 8030, 8032, 8035 ZTS
Backhoe Loaders 1CX (All series)

The bucket fits machines with standard mounting: 35mm pin, 135mm arm, 130mm spacing. Does not fit smaller (8018) or larger (3CX) machines.

Related Parts and Hardware

The bucket is supplied with teeth and bushings. The set does not include mounting pins (use old ones or buy new ones with a diameter of 35mm). We also offer pins and quick couplers for this model.

⚠️ Safety Warning

Using buckets with incorrect pin spacing can lead to damage to the quick coupler or excavator arm. Always ensure that the mounting dimensions match your machine's specifications (35/135/130 mm).

Part Role in the Machine and Failure Diagnostics

The 40 cm bucket is used for trenches for foundations, drainage, and cables.

  • › Blunt teeth (difficulty digging, higher fuel consumption).
  • › Pin play (worn bushings, knocking).
  • › Weld cracks (overload, working as a hammer).
  • › Bucket bottom wear (long-term work in abrasive ground).

📞 Can't find the part you're looking for?

No worries. Our website features only a few thousand of the over 60,000 parts we have in stock. Contact us – we likely have what you need readily available!

🔧 Expert Guide: Key Installation Tips

  1. Dimensions Verification: Before purchasing, check the pin diameter (35mm). JCB 8014-8018 models have smaller pins (25mm), and 8040-8050 have larger ones (45mm). This bucket fits the medium series (8025-8035).
  2. Lubrication: The new bucket has new bushings. Grease the pins abundantly after installation to ensure smooth operation and avoid seizure.
  3. Teeth: Check teeth tightening after the first few hours of work. Vibrations can loosen bolts in new attachments.

Technical FAQ and Trivia

What is the bucket capacity?

Model 980/90470 has a capacity of 68 liters. It is a compromise between digging efficiency and spoil weight, adapted to the stability of 2.5-3.5 ton mini excavators.

Does it fit JCB 8018?

No. The 8018 model has 25 mm diameter pins. This bucket is for 35 mm pins. Installation will be impossible (too much play).

Trivia about JCB 1CX

The JCB 1CX is a unique machine - the smallest backhoe loader in the world, built on a skid steer chassis. Thanks to this, it shares the excavator bucket standard with the 8025/8030 series mini excavators (35mm pin), which facilitates attachment management in companies owning both machines.

Question mark

Do you have doubts or need confirmation to avoid costly downtime? Call us. Our experts will help you select the right part to get your equipment back to work as quickly as possible.

SKX825215HM
980/90470
58.00 kg

Data sheet

SUITABLE FOR
JCB
MACHINE TYPE
BACKHOE LOADER
MINIEXCAVATOR
WIDTH (MM)
400
NUMBER OF TEETH
3
PINS (MM)
35
ARM WIDTH (MM)
135
SPACING OF THE PINS (MM)
130

Specific References

MPN
980/90470
Łączna ocena:
0,0
Kupiłeś ten produkt? Napisz recenzję dla innych!
Be the first to write your review !
Opinion:
(0 opinions)

Write a review

Bucket 40cm suitable for JCB 8025/803/8035, 1CX mini excavators

Catalog number: SKX825215HM
Title for your review*
Your review*
Your name*
Your email*

Manufacturer

  • Serwis Kop Sp. z o.o. Sp. K.
  • Podkarpacka 57A
  • 35-082 Rzeszów
  • Poland
  • [email protected]
  • +48178643100

Responsible person

  • Serwis Kop Sp. z o.o. Sp. K.
  • Podkarpacka 57A
  • 35-082 Rzeszów
  • Poland
  • [email protected]
  • +48178643100
gross price

1,279.20 zł

net price
1040,00 zł
Available in large quantity Temporarily unavailable
1040,00 zł
net price

1,279.20 zł

gross price
Nie możesz dodać więcej produktów
  • You will receive 104 points, it gives you 41.60 zł
  • Lowest price from 30 days before the discount: 1,279.20 zł
    PRODUCT SPECIFICATION
    SUITABLE FOR
    JCB
    MACHINE TYPE
    BACKHOE LOADER
    MINIEXCAVATOR
    WIDTH (MM)
    400
    NUMBER OF TEETH
    3
    PINS (MM)
    35
    ARM WIDTH (MM)
    135
    SPACING OF THE PINS (MM)
    130
