Grading bucket 120 cm / LEHNHOFF MS03
HIMACORE

Grading bucket 120 cm / LEHNHOFF MS03 - NEXGEN

Catalog number:SKX828369HM Nr OEM:BG120-MS03 Manufacturer:HIMACORE
Add a review

Grading Bucket 120cm Lehnhoff MS03 - BG120-MS03

Technical Specification and Compatibility

Rigid grading bucket with a width of 120 cm (1200 mm) and part number BG120-MS03, manufactured by HIMACORE. This attachment is dedicated to mini excavators (weight 1.5 – 5 tons) equipped with the popular LEHNHOFF MS03 mechanical quick coupler system. The bucket is ready to work, featuring an integrated adapter plate compatible with this system.

Part Number: BG120-MS03
Component Type: Grading/Ditching Bucket
Working Width: 1200 mm (120 cm)
Mounting System: Lehnhoff MS03
Blade Material: G2 Structural Steel
Body Material: Quality Steel
Application (Machine Weight): approx. 1.5 - 5 tons
Manufacturer: HIMACORE

HIMACORE attachments with MS03 mounting guarantee quick and safe tool changes. Thanks to robust construction and the use of G2 steel, the bucket excels in land leveling and grading tasks in light to medium soils.

Guide to Lehnhoff Systems

The Lehnhoff coupler family is an industry standard. Below is a brief characteristic of each system to help select the right solution:

1. Lehmatic MS – Mechanical Quick Couplers

  • MS01: For mini excavators 0.7 – 2 t.
  • MS03: For mini/compact excavators 1.5 – 5 t (This bucket uses this system).
  • MS08 / MS10: For larger excavators (up to approx. 45 t).
  • Usage: The simplest, wear-resistant solution. Locking via key/bolt.

2. Lehmatic HS – Hydraulic Quick Couplers

  • Locking via a double-acting cylinder; controlled from the cab.
  • Usage: For operators valuing speed – changing buckets without leaving the machine (e.g., HS 08 for 6-12t machines).

3. Variolock (VL) – Fully Automatic System

  • Automatic connection of hydraulic lines (hammers, grabs, augers).
  • Usage: Maximum productivity with frequent hydraulic attachment changes.

4. Symmetric / SQ-V

  • Symmetrical standard with automatic hydraulic connection.
  • Usage: Easier attachment logistics (ability to mount bucket "reversed") + full automation.

Features of HIMACORE BG120-MS03 Bucket

MS03 System: Integrated MS03 adapter plate allows instant bucket attachment to the quick coupler without the need to hammer pins.
G2 Blade: Made of G2 structural steel, providing a good strength-to-weight ratio, which is important in mini excavators to avoid overloading the arm.
120cm Width: Optimal size for grading, leveling, and backfilling trenches for machines in the 1.5-5 ton class.
Rigid Construction: Body made of quality steel is resistant to deformation when working with loose material.

Application (MS03 System)

Mounting System Machine Class
Lehnhoff MS03 Mini excavators with an operating weight of approx. 1.5 to 5.0 tons (regardless of brand: JCB, Kubota, Yanmar, Takeuchi, CAT etc., provided they have an MS03 coupler)

Note: Adapter geometry (spacing, width) must match your MS03 quick coupler.

Related Parts and Hardware

The bucket is supplied without pins (in the MS03 system, pins are part of the adapter/plate and are integrated into the bucket structure). To lock the bucket in the mechanical coupler, a locking bolt key is needed (part of the machine's quick coupler).

⚠️ Safety Warning

In the MS mechanical system, after attaching the bucket, you must always manually tighten the locking bolt until fully latched. Working with an unsecured quick coupler risks bucket detachment and a serious accident. Check the lock status before starting work!

Part Role in the Machine and Failure Diagnostics

The grading bucket is used for ground leveling and cleanup works.

  • › Play on coupler (wear of adapter plate or quick coupler latches).
  • › Blade wear (natural wear of the cutting edge).
  • › Bucket bending (working on hard ground, overload).
  • › Difficulty latching (dirt in MS03 sockets).

📞 Can't find the part you're looking for?

Do you have doubts or need confirmation to avoid costly downtime? Call us. Our experts will help you select the right part to get your equipment back to work as quickly as possible.

🔧 Expert Guide: Key Installation Tips

  1. Coupler Cleanliness: Before attaching the bucket, always clean soil and stones from the adapter plate and quick coupler socket. Debris will prevent proper latching.
  2. System Verification: Ensure you have the MS03 system (for 1.5-5t machines). The MS01 system (up to 2t) looks similar but is smaller and will not fit.
  3. Maintenance: Regularly grease the locking bolt mechanism in the mechanical quick coupler to ensure easy attachment exchange.

Technical FAQ and Trivia

What is the Lehnhoff system?

The Lehnhoff (Lehmatic) system is one of the most popular excavator quick coupler standards in Europe. It allows for lightning-fast attachment changes without having to knock out pins with a hammer. The MS (Mechanical) and HS (Hydraulic) systems are the basis for efficient work on the construction site.

Does this bucket fit a Kubota?

Yes, provided your Kubota (e.g., KX018, U27) is equipped with an MS03 standard quick coupler. The excavator model itself does not define the coupler - it is often added by the dealer.

Trivia about Lehnhoff company

Lehnhoff Hartstahl, the creator of the Lehmatic system, started as... a repair shop. Over time, seeing problems with bucket changing, they developed a system that revolutionized the market, becoming the de facto industrial standard in Germany and Central Europe.

Question mark

Do you have doubts or need confirmation to avoid costly downtime? Call us. Our experts will help you select the right part to get your equipment back to work as quickly as possible.

SKX828369HM
BG120-MS03
