Hydraulic grading bucket 120cm suitable for JCB 802 803 - COBRA
HIMACORE

Hydraulic grading bucket 120cm suitable for JCB 8025/803/8035, 1CX

Catalog number:SKX827274HM Nr OEM:522/03000 Manufacturer:HIMACORE
Add a review

120cm Hydraulic Tilting Bucket (HB400) suitable for JCB 8025 1CX - 522/03000

Technical Specification and Compatibility

Technologically advanced 1200 mm (120 cm) hydraulic grading bucket by HIMACORE. This attachment is dedicated to JCB mini excavators (8025-8035 series) and 1CX compact backhoe loaders. It allows for precise terrain profiling at any angle thanks to the hydraulic cylinder. The product is complete and ready to be connected to the machine's hydraulic line.

Part Number: 522/03000
Type: Hydraulic Grading Bucket / Tilting Ditching Bucket
Working Width: 1200 mm (120 cm)
Capacity (ISO 7451): 112 Liters
Cutting Edge Material: HB400 Wear-Resistant Steel
Body Thickness: 5 mm
Hitch Dimensions: 35mm Pins / 135mm Width / 130mm Spacing

HIMACORE hydraulic attachments combine robust mechanics with reliable power hydraulics. Reinforced hitch construction and high-grade blade steel guarantee long life and work precision expected by professional operators.

Features of HIMACORE 120cm Hydraulic Bucket

Tilting System: Integrated hydraulic cylinder allows smooth adjustment of the bucket angle (left/right), invaluable for grading slopes and ditches.
Reinforced Hitch: The bucket head is designed to withstand torsional loads generated by the cylinder and digging forces.
HB400 Blade: Cutting edge made of certified 400 HB hardness steel ensures resistance to abrasion in contact with soil.
Universal Mounting: Hitch compatible with JCB standard (35/135/130) allows direct mounting on pins or via compatible quick hitches.

Application in machinery

Brand Models
JCB (Mini Excavators) 8025, 8026 CTS, 8027, 8030, 8032, 8035 ZTS
JCB (Backhoe Loaders) 1CX (models with auxiliary hydraulics on the arm)

An additional hydraulic line on the excavator arm is required to control the bucket cylinder.

Related Parts and Hardware

To mount the bucket, two 35 mm diameter pins are required (not included in the set). You also need hydraulic hoses matching the length of your machine's arm and appropriate hydraulic couplers.

⚠️ Safety Warning

When working with a hydraulic bucket, be careful not to pinch or tear the hydraulic hoses. Never use the bucket cylinder to push heavy objects sideways, as this risks bending the rod.

Part Role in the Machine and Failure Diagnostics

The tilting bucket allows for precise profiling of slopes and ditches without constantly repositioning the machine on uneven terrain.

  • › Cylinder oil leak (damaged seals).
  • › Bucket drift (internal leak in cylinder or valve block).
  • › Play on tilting head pins.
  • › Worn blade (need to replace the flat bar).

📞 Can't find the part you're looking for?

No worries. Our website features only a few thousand of the over 60,000 parts we have in stock. Contact us – we likely have what you need readily available!

🔧 Expert Guide: Key Installation Tips

  1. Check Dimensions: This bucket has a 35/135/130 hitch. It fits JCB 8025-8035, but does not fit smaller 8018 (25mm pins) or larger 8040 (40/45mm pins).
  2. Hydraulic Installation: Ensure your mini excavator has a bi-directional (auxiliary) hydraulic line on the arm.
  3. Head Lubrication: The tilting mechanism has additional grease points (nipples). Regular lubrication is key for smooth operation.

Frequently Asked Questions (FAQ)

Does the bucket include hydraulic hoses?

Standardly, the bucket is sold with the cylinder but without hoses, as their length and coupler type depend on the customer's specific machine configuration.

Does it fit a quick hitch?

Yes, the bucket hitch is made to JCB standard (35/135/130), so it fits mechanical and hydraulic quick hitches dedicated to these models.

What steel is the blade made of?

The cutting edge is made of wear-resistant steel with a hardness of 400 HB (HB400), ensuring high wear resistance in difficult conditions.

Question mark

Do you have doubts or need confirmation to avoid costly downtime? Call us. Our experts will help you select the right part to get your equipment back to work as quickly as possible.

SKX827274HM
522/03000
138.00 kg

Data sheet

SUITABLE FOR
JCB
MACHINE TYPE
MINIEXCAVATOR
OEM NUMBERS
522/03000
WIDTH (MM)
1200
PINS (MM)
35
ARM WIDTH (MM)
135
SPACING OF THE PINS (MM)
130

Specific References

MPN
522/03000
Łączna ocena:
0,0
Kupiłeś ten produkt? Napisz recenzję dla innych!
Be the first to write your review !
Opinion:
(0 opinions)

Write a review

Hydraulic grading bucket 120cm suitable for JCB 8025/803/8035, 1CX

Catalog number: SKX827274HM
Title for your review*
Your review*
Your name*
Your email*

Manufacturer

  • Serwis Kop Sp. z o.o. Sp. K.
  • Podkarpacka 57A
  • 35-082 Rzeszów
  • Poland
  • [email protected]
  • +48178643100

Responsible person

  • Serwis Kop Sp. z o.o. Sp. K.
  • Podkarpacka 57A
  • 35-082 Rzeszów
  • Poland
  • [email protected]
  • +48178643100
gross price

4,569.45 zł

net price
3715,00 zł
Available in large quantity Temporarily unavailable
3715,00 zł
net price

4,569.45 zł

gross price
Nie możesz dodać więcej produktów
  • You will receive 372 points, it gives you 148.80 zł
  • Lowest price from 30 days before the discount: 4,569.45 zł
    PRODUCT SPECIFICATION
    SUITABLE FOR
    JCB
    MACHINE TYPE
    MINIEXCAVATOR
    OEM NUMBERS
    522/03000
    WIDTH (MM)
    1200
    PINS (MM)
    35
    ARM WIDTH (MM)
    135
    SPACING OF THE PINS (MM)
    130
