Grading bucket 100 cm / LEHNHOFF MS01
HIMACORE

Grading bucket 100 cm / LEHNHOFF MS01

Catalog number:SKX828348HM Nr OEM:BG100-MS01 Manufacturer:HIMACORE
Add a review

Grading Bucket 100cm Lehnhoff MS01 - BG100-MS01

Technical Specification and Compatibility

Rigid grading bucket with a width of 100 cm (1000 mm) and part number BG100-MS01, manufactured by HIMACORE. It is an attachment designed for micro-excavators and mini excavators in the weight range of 0.7 – 2.0 tons, equipped with the LEHNHOFF MS01 quick coupler system. The bucket is brand new, complete (integrated adapter), and ready for grading and leveling work.

Part Number: BG100-MS01
Component Type: Rigid Grading Bucket
Working Width: 1000 mm (100 cm)
Mounting System: Lehnhoff MS01
Blade Material: G2 Structural Steel
Body Material: Quality Steel
Application: Machines 0.7 - 2.0 t
Manufacturer: HIMACORE

HIMACORE products offer solid solutions at an affordable price. The use of G2 steel in the blade ensures adequate durability for light machines, and the integrated MS01 adapter guarantees instant attachment replacement on the construction site.

Guide to Lehnhoff Systems

The Lehnhoff coupler family is an industry standard. Below is a brief characteristic of each system to help select the right solution:

1. Lehmatic MS – Mechanical Quick Couplers

  • MS01: For mini excavators 0.7 – 2 t (This bucket uses this system).
  • MS03: For mini/compact excavators 1.5 – 5 t (Larger standard).
  • MS08 / MS10: For larger excavators (up to approx. 45 t).
  • Usage: The simplest, wear-resistant solution. Locking via key/bolt.

2. Lehmatic HS – Hydraulic Quick Couplers

  • Locking via a double-acting cylinder; controlled from the cab.
  • Usage: For operators valuing speed – changing buckets without leaving the machine.

3. Variolock (VL) – Fully Automatic System

  • Automatic connection of hydraulic lines (hammers, grabs, augers).
  • Usage: Maximum productivity with frequent hydraulic attachment changes.

4. Symmetric / SQ-V

  • Symmetrical standard with automatic hydraulic connection.
  • Usage: Easier attachment logistics (ability to mount bucket "reversed") + full automation.

Features of HIMACORE BG100-MS01 Bucket

100cm Width: Provides excellent efficiency when leveling the ground and backfilling trenches, without overloading the hydraulics of small excavators.
MS01 System: Factory-built MS01 adapter (40 mm shafts) ensures full compatibility with the most popular quick coupler system in the mini class.
G2 Blade: Made of G2 structural steel, offers a good balance between weight and strength, which is key for the stability of light machines.
Lightweight Design: Optimized bucket weight allows maintaining the full reach and lifting capacity of the micro-excavator.

Application (MS01 System)

Mounting System Machine Class
Lehnhoff MS01 Micro-excavators and mini excavators with an operating weight of approx. 0.7 to 2.0 tons (regardless of brand: JCB, Kubota, Yanmar, Takeuchi, CAT, Wacker Neuson etc., provided they have an MS01 coupler)

Note: The MS01 system is significantly smaller than MS03. Check if your machine has the appropriate quick coupler (40mm shafts).

Related Parts and Hardware

The bucket is supplied without loose pins (in the MS01 system, mounting shafts are an integral part of the adapter plate welded into the bucket). To lock the bucket in the mechanical coupler, a locking bolt key is needed (part of the machine's equipment).

⚠️ Safety Warning

Working with a wide bucket (100 cm) on a small excavator (e.g., 1 ton) requires caution. A full bucket of wet soil at full reach can cause the machine to lose stability. Always lower the bucket low when rotating.

Part Role in the Machine and Failure Diagnostics

The grading bucket is used for smoothing, leveling, and loading light materials.

  • › Play on coupler (wear of MS01 adapter shafts).
  • › Blade wear (rounding of the cutting edge).
  • › Bucket bending (working on hard, rocky ground).
  • › Difficulty latching (dirt in socket).

📞 Can't find the part you're looking for?

Do you have doubts or need confirmation to avoid costly downtime? Call us. Our experts will help you select the right part to get your equipment back to work as quickly as possible.

🔧 Expert Guide: Key Installation Tips

  1. Identification: Check your quick coupler. MS01 has shafts with a diameter of 40 mm and an adapter width of approx. 183 mm. MS03 is much larger (50 mm shafts).
  2. Cleanliness: Always remove dirt from the space between the adapter shafts before attaching. Even a small stone will prevent proper latching.
  3. Maintenance: Grease the screw mechanism in the machine's quick coupler to ensure smooth bucket attachment and detachment.

Technical FAQ and Trivia

Does it fit MS03?

No. This bucket has an MS01 adapter, which is too small for the MS03 coupler. Attempting to attach it will be impossible due to the difference in spacing and shaft diameter.

Does the bucket have teeth?

No, this is a grading bucket. It has a smooth blade, used for leveling the ground, not for aggressive digging, so teeth are not installed.

Trivia about MS01

The MS01 system is the smallest of the Lehmatic family, but paradoxically one of the most loaded relative to size. In micro-excavators, operators often use buckets as wide as the undercarriage (like this 100cm one), which puts huge demands on the small coupler.

Question mark

Do you have doubts or need confirmation to avoid costly downtime? Call us. Our experts will help you select the right part to get your equipment back to work as quickly as possible.

SKX828348HM
BG100-MS01
55.00 kg

Data sheet

SUITABLE FOR
BOBCAT
CASE
CAT
FIAT HITACHI
HITACHI
JCB
KOBELCO
KUBOTA
NEUSON
NEW HOLLAND
TAKEUCHI
VOLVO
YANMAR
MACHINE TYPE
BACKHOE LOADER
MINIEXCAVATOR
WIDTH (MM)
1000

Specific References

MPN
BG100-MS01
