Bucket 40 cm / LEHNHOFF MS03 - NEXGEN

Catalog number:SKX828361HM Nr OEM:B40MS03 Manufacturer:HIMACORE
Add a review

Excavator Bucket 40cm Lehnhoff MS03 - B40MS03

Technical Specification and Compatibility

Excavator bucket with a width of 40 cm (400 mm) and part number B40MS03, manufactured by HIMACORE. It is a versatile digging bucket, dedicated to mini excavators in the weight range of 1.5 – 5 tons, equipped with the LEHNHOFF MS03 quick coupler system. The bucket is brand new, complete, and ready to work.

Part Number: B40MS03
Component Type: Excavator Bucket 400mm
Working Width: 400 mm (40 cm)
Mounting System: Lehnhoff MS03
Blade Material: G2 Structural Steel
Body Material: Quality Steel
Equipment: Teeth included
Manufacturer: HIMACORE

HIMACORE attachments are characterized by solid workmanship and the use of proven materials. The integrated MS03 plate ensures lightning-fast attachment changes, significantly increasing work efficiency on the construction site.

Guide to Lehnhoff Systems

The Lehnhoff coupler family is an industry standard. Below is a brief characteristic of each system to help select the right solution:

1. Lehmatic MS – Mechanical Quick Couplers

  • MS01: For mini excavators 0.7 – 2 t.
  • MS03: For mini/compact excavators 1.5 – 5 t (This bucket uses this system).
  • MS08 / MS10: For larger excavators (up to approx. 45 t).
  • Usage: The simplest, wear-resistant solution. Locking via key/bolt.

2. Lehmatic HS – Hydraulic Quick Couplers

  • Locking via a double-acting cylinder; controlled from the cab.
  • Usage: For operators valuing speed – changing buckets without leaving the machine (e.g., HS 08 for 6-12t machines).

3. Variolock (VL) – Fully Automatic System

  • Automatic connection of hydraulic lines (hammers, grabs, augers).
  • Usage: Maximum productivity with frequent hydraulic attachment changes.

4. Symmetric / SQ-V

  • Symmetrical standard with automatic hydraulic connection.
  • Usage: Easier attachment logistics (ability to mount bucket "reversed") + full automation.

Features of HIMACORE B40MS03 Bucket

40cm Width: Ideal for utility trenches, foundations, and drainage works, offering a balance between capacity and digging precision.
MS03 System: Integrated Lehnhoff MS03 adapter ensures compatibility with a huge number of mini excavators available on the European market.
G2 Blade: The use of G2 structural steel provides good weldability and sufficient hardness for standard construction applications.
Complete Set: The bucket is equipped with teeth that facilitate ground penetration. It is ready to attach and work right after delivery.

Application (MS03 System)

Mounting System Machine Class
Lehnhoff MS03 Mini excavators with an operating weight of approx. 1.5 to 5.0 tons (regardless of brand: JCB, Kubota, Yanmar, Takeuchi, CAT etc., provided they have an MS03 coupler)

Note: Before purchasing, ensure your machine has an MS03 standard quick coupler.

Related Parts and Hardware

The bucket is supplied with teeth, but without loose pins (in the MS03 system, mounting shafts are an integral part of the adapter plate welded into the bucket). To lock the bucket in the mechanical coupler, a locking bolt key is needed (usually supplied with the machine).

⚠️ Safety Warning

Improper locking of a mechanical quick coupler is a common cause of accidents. After changing the bucket, always ensure the locking bolt is tightened to the stop and the bucket has no play in the socket.

Part Role in the Machine and Failure Diagnostics

The 40 cm bucket is used for general excavation work.

  • › Teeth wear (reduced digging efficiency).
  • › Adapter play (worn MS03 shafts).
  • › Body cracks (overload).
  • › Connection problems (dirty quick coupler socket).

📞 Can't find the part you're looking for?

Do you have doubts or need confirmation to avoid costly downtime? Call us. Our experts will help you select the right part to get your equipment back to work as quickly as possible.

🔧 Expert Guide: Key Installation Tips

  1. Cleaning: Before attempting to attach the bucket, remove mud and stones from the space between the adapter shafts. Even a small stone can prevent latching.
  2. Identification: Check the marking on your quick coupler. MS03 (for 1.5-5t machines) and MS01 (up to 2t) are incompatible despite looking similar.
  3. Maintenance: Regularly grease the locking bolt mechanism in the mechanical quick coupler to ensure easy attachment exchange.

Technical FAQ and Trivia

What does MS stand for?

The abbreviation MS in the Lehnhoff MS03 name comes from German "Mechanisches Schnellwechselsystem", which simply means Mechanical Quick Change System.

Does this bucket fit MS01?

No. The MS01 system is smaller (for machines up to 2 tons). This bucket has an MS03 adapter, which is wider and has thicker shafts, designed for 1.5-5 ton machines.

Trivia about Lehnhoff

Lehnhoff Hartstahl, the creator of the Lehmatic system, started as... a repair shop. Over time, seeing problems with bucket changing, they developed a system that revolutionized the market, becoming the de facto industrial standard in Germany and Central Europe.

Znak zapytania

Do you have doubts or need confirmation to avoid costly downtime? Call us. Our experts will help you select the right part to get your equipment back to work as quickly as possible.

SKX828361HM
B40MS03
71.00 kg

Data sheet

SUITABLE FOR
BOBCAT
CASE
CAT
FIAT HITACHI
HITACHI
JCB
KOBELCO
KOMATSU
NEUSON
NEW HOLLAND
TAKEUCHI
TEREX
VOLVO
YANMAR
MACHINE TYPE
BACKHOE LOADER
MINIEXCAVATOR
OEM NUMBERS
B40MS03
WIDTH (MM)
400
NUMBER OF TEETH
3

Specific References

MPN
B40MS03
Łączna ocena:
0,0
Kupiłeś ten produkt? Napisz recenzję dla innych!
Be the first to write your review !
Opinion:
(0 opinions)

Write a review

Bucket 40 cm / LEHNHOFF MS03 - NEXGEN

Catalog number: SKX828361HM
Title for your review*
Your review*
Your name*
Your email*

Manufacturer

  • Serwis Kop Sp. z o.o. Sp. K.
  • Podkarpacka 57A
  • 35-082 Rzeszów
  • Poland
  • [email protected]
  • +48178643100

Responsible person

  • Serwis Kop Sp. z o.o. Sp. K.
  • Podkarpacka 57A
  • 35-082 Rzeszów
  • Poland
  • [email protected]
  • +48178643100
gross price

1,720.77 zł

net price
1399,00 zł
Last pieces Temporarily unavailable
1399,00 zł
net price

1,720.77 zł

gross price
Nie możesz dodać więcej produktów
  • You will receive 140 points, it gives you 56.00 zł
  • Lowest price from 30 days before the discount: 1,720.77 zł
    PRODUCT SPECIFICATION
    SUITABLE FOR
    BOBCAT
    CASE
    CAT
    FIAT HITACHI
    HITACHI
    JCB
    KOBELCO
    KOMATSU
    NEUSON
    NEW HOLLAND
    TAKEUCHI
    TEREX
    VOLVO
    YANMAR
    Show more
    MACHINE TYPE
    BACKHOE LOADER
    MINIEXCAVATOR
    OEM NUMBERS
    B40MS03
    WIDTH (MM)
    400
    NUMBER OF TEETH
    3
