Bucket 60 cm / LEHNHOFF MS03
HIMACORE

Bucket 60 cm / LEHNHOFF MS03 - NEXGEN

Catalog number:SKX828365HM Nr OEM:B60MS03 Manufacturer:HIMACORE
Add a review

Excavator Bucket 60cm Lehnhoff MS03 - B60MS03

Technical Specification and Compatibility

Excavator bucket with a width of 60 cm (600 mm) and part number B60MS03, manufactured by HIMACORE. It is a universal digging bucket, dedicated to mini excavators in the weight range of 1.5 – 5 tons, equipped with the LEHNHOFF MS03 quick coupler system. The bucket is brand new, complete, and ready for immediate work.

Part Number: B60MS03
Component Type: Excavator Bucket 600mm
Working Width: 600 mm (60 cm)
Mounting System: Lehnhoff MS03
Blade Material: G2 Structural Steel
Body Material: Quality Steel
Equipment: Teeth included
Manufacturer: HIMACORE

HIMACORE attachments feature solid construction and perfect alignment with market standards. The integrated MS03 adapter ensures quick attachment replacement, and the G2 blade guarantees adequate durability for standard earthworks.

Guide to Lehnhoff Systems

The Lehnhoff coupler family is an industry standard. Below is a brief characteristic of each system to help select the right solution:

1. Lehmatic MS – Mechanical Quick Couplers

  • MS01: For mini excavators 0.7 – 2 t.
  • MS03: For mini/compact excavators 1.5 – 5 t (This bucket uses this system).
  • MS08 / MS10: For larger excavators (up to approx. 45 t).
  • Usage: The simplest, wear-resistant solution. Locking via key/bolt.

2. Lehmatic HS – Hydraulic Quick Couplers

  • Locking via a double-acting cylinder; controlled from the cab.
  • Usage: For operators valuing speed – changing buckets without leaving the machine (e.g., HS 08 for 6-12t machines).

3. Variolock (VL) – Fully Automatic System

  • Automatic connection of hydraulic lines (hammers, grabs, augers).
  • Usage: Maximum productivity with frequent hydraulic attachment changes.

4. Symmetric / SQ-V

  • Symmetrical standard with automatic hydraulic connection.
  • Usage: Easier attachment logistics (ability to mount bucket "reversed") + full automation.

Features of HIMACORE B60MS03 Bucket

Universal 60cm Width: The most popular size for digging foundations, utility trenches, and general earthworks.
MS03 System: Integrated Lehnhoff MS03 adapter ensures compatibility with a huge number of mini excavators available on the European market.
G2 Blade: The use of G2 structural steel provides good weldability and sufficient hardness for standard construction applications.
Complete Set: The bucket is equipped with teeth that facilitate ground penetration. It is ready to attach and work right after delivery.

Application (MS03 System)

Mounting System Machine Class
Lehnhoff MS03 Mini excavators with an operating weight of approx. 1.5 to 5.0 tons (regardless of brand: JCB, Kubota, Yanmar, Takeuchi, CAT etc., provided they have an MS03 coupler)

Note: Before purchasing, ensure your machine has an MS03 standard quick coupler.

Related Parts and Hardware

The bucket is supplied with teeth, but without loose pins (in the MS03 system, mounting shafts are an integral part of the adapter plate welded into the bucket). To lock the bucket, a quick coupler key is needed (usually supplied with the machine).

⚠️ Safety Warning

Improper locking of a mechanical quick coupler is a common cause of accidents. After changing the bucket, always ensure the locking bolt is tightened to the stop and the bucket has no play in the socket.

Part Role in the Machine and Failure Diagnostics

The 60 cm bucket is used for general excavation and loading work.

  • › Teeth wear (reduced digging efficiency).
  • › Adapter play (worn MS03 shafts).
  • › Body cracks (overload).
  • › Connection problems (dirty quick coupler socket).

📞 Can't find the part you're looking for?

Do you have doubts or need confirmation to avoid costly downtime? Call us. Our experts will help you select the right part to get your equipment back to work as quickly as possible.

🔧 Expert Guide: Key Installation Tips

  1. Cleaning: Before attempting to attach the bucket, remove mud and stones from the space between the adapter shafts. Even a small stone can prevent latching.
  2. Identification: Check the marking on your quick coupler. MS03 (for 1.5-5t machines) and MS01 (up to 2t) are incompatible despite looking similar.
  3. Maintenance: Regularly check the condition of the teeth. Replace them before wear reaches the tooth adapter or bucket blade.

Technical FAQ and Trivia

Does this bucket fit JCB 8018?

Only if the machine has been retrofitted with a Lehnhoff MS03 quick coupler. From the factory, JCB uses its own pin standard, so this bucket will not fit directly onto the arm without an MS03 adapter.

What is Symlock?

Symlock is an improved version of the Lehnhoff adapter that allows the bucket to be attached in both directions (as a backhoe and face shovel). Standard MS03 (without Symlock) allows attachment in only one direction.

Universality trivia

The MS03 system is so widespread that it is often chosen by companies with a mixed fleet of machines (e.g., Kubota, Yanmar, JCB), allowing them to use the same set of buckets for all excavators in the 2-4 ton class.

Question mark

Do you have doubts or need confirmation to avoid costly downtime? Call us. Our experts will help you select the right part to get your equipment back to work as quickly as possible.

SKX828365HM
B60MS03
88.00 kg

Data sheet

MACHINE TYPE
BACKHOE LOADER
MINIEXCAVATOR
OEM NUMBERS
B60MS03
WIDTH (MM)
600

Specific References

MPN
B60MS03
