Bucket 60 cm / LEHNHOFF MS01
HIMACORE

Bucket 60 cm / LEHNHOFF MS01 - NEXGEN

Catalog number:SKX828345HM Nr OEM:B60MS01 Manufacturer:HIMACORE
Add a review

Excavator Bucket 60cm Lehnhoff MS01 - B60MS01

Technical Specification and Compatibility

Excavator bucket with a width of 60 cm (600 mm) and part number B60MS01, manufactured by HIMACORE. It is a universal digging bucket, dedicated to the smallest mini excavators in the weight range of 0.7 – 2.0 tons, equipped with the LEHNHOFF MS01 quick coupler system. The bucket is brand new, complete, and ready for immediate work on the construction site.

Part Number: B60MS01
Component Type: Excavator Bucket 600mm
Working Width: 600 mm (60 cm)
Mounting System: Lehnhoff MS01
Blade Material: G2 Structural Steel
Body Material: Quality Steel
Equipment: Teeth included
Manufacturer: HIMACORE

HIMACORE attachments with MS01 adapter are the perfect solution for micro-excavators. The lightweight yet durable construction does not overload the machine arm, allowing for efficient work in foundation and utility trenches.

Guide to Lehnhoff Systems

The Lehnhoff coupler family is an industry standard. Below is a brief characteristic of each system to help select the right solution:

1. Lehmatic MS – Mechanical Quick Couplers

  • MS01: For mini excavators 0.7 – 2 t (This bucket uses this system).
  • MS03: For mini/compact excavators 1.5 – 5 t (Larger standard).
  • MS08 / MS10: For larger excavators (up to approx. 45 t).
  • Usage: The simplest, wear-resistant solution. Locking via key/bolt.

2. Lehmatic HS – Hydraulic Quick Couplers

  • Locking via a double-acting cylinder; controlled from the cab.
  • Usage: For operators valuing speed – changing buckets without leaving the machine.

3. Variolock (VL) – Fully Automatic System

  • Automatic connection of hydraulic lines (hammers, grabs, augers).
  • Usage: Maximum productivity with frequent hydraulic attachment changes.

4. Symmetric / SQ-V

  • Symmetrical standard with automatic hydraulic connection.
  • Usage: Easier attachment logistics (ability to mount bucket "reversed") + full automation.

Features of HIMACORE B60MS01 Bucket

MS01 System: Integrated adapter plate fits the smallest Lehnhoff MS01 quick couplers, which is standard in micro-excavators (e.g., Kubota K008, Yanmar SV08).
60cm Width: This is a "large" bucket for this class of machines, ideal for quickly removing spoil and backfilling trenches.
G2 Blade: Made of G2 structural steel, it provides optimal strength for light machines without unnecessarily increasing attachment weight.
Teeth Included: The bucket has replaceable teeth that facilitate work in harder ground and protect the main blade from wear.

Application (MS01 System)

Mounting System Machine Class
Lehnhoff MS01 Micro-excavators and mini excavators with an operating weight of approx. 0.7 to 2.0 tons (regardless of brand: JCB, Kubota, Yanmar, Takeuchi, CAT, Wacker Neuson etc., provided they have an MS01 coupler)

Note: The MS01 system is significantly smaller than MS03. Ensure your machine has the correct quick coupler.

Related Parts and Hardware

The bucket is supplied with teeth, but without loose pins (in the MS01 system, mounting shafts are an integral part of the adapter plate). To lock, a quick coupler key (hex or special) is needed.

⚠️ Safety Warning

In small excavators (under 2 tons), it is easy to overload when using a wide bucket (60 cm) filled with wet soil. Exercise caution at full reach and rotation to avoid tipping the machine.

Part Role in the Machine and Failure Diagnostics

The 60 cm bucket is used for efficient digging and loading.

  • › Worn teeth (difficulty penetrating soil).
  • › Play on coupler (worn MS01 adapter shafts).
  • › Weld cracks (overload).
  • › Dirty sockets (unable to attach).

📞 Can't find the part you're looking for?

Do you have doubts or need confirmation to avoid costly downtime? Call us. Our experts will help you select the right part to get your equipment back to work as quickly as possible.

🔧 Expert Guide: Key Installation Tips

  1. Identification: Check your quick coupler. MS01 has shafts with a diameter of 40 mm and an adapter width of approx. 183 mm. MS03 is much larger (50 mm shafts).
  2. Cleanliness: Always remove dirt from the space between the adapter shafts before attaching. Even a small stone will prevent proper latching.
  3. Maintenance: Grease the screw mechanism in the machine's quick coupler to ensure smooth bucket attachment and detachment.

Technical FAQ and Trivia

Does it fit MS03?

No. This bucket has an MS01 adapter, which is too small for the MS03 coupler. Attempting to attach it will be impossible due to the difference in spacing and shaft diameter.

How much does this bucket weigh?

MS01 buckets are light, typically weighing between 40 and 60 kg (depending on width), which allows maintaining the lifting capacity and stability of small excavators.

Popularity trivia

The MS01 system is the "de facto" standard for micro-excavators in many Western European countries. This allows rental companies to easily swap attachments between machines of different manufacturers (e.g., Bobcat, Kubota, Yanmar), as long as they have this coupler.

Question mark

Do you have doubts or need confirmation to avoid costly downtime? Call us. Our experts will help you select the right part to get your equipment back to work as quickly as possible.

SKX828345HM
B60MS01
57.00 kg

Data sheet

SUITABLE FOR
BOBCAT
CASE
CAT
FIAT HITACHI
HIDROMEK
JCB
NEUSON
NEW HOLLAND
TAKEUCHI
TEREX
VOLVO
MACHINE TYPE
BACKHOE LOADER
MINIEXCAVATOR
OEM NUMBERS
B60MS01
WIDTH (MM)
600
NUMBER OF TEETH
4

Specific References

MPN
B60MS01
