Grading bucket 100cm suitable for CAT 302, 302.5 CR mini excavators
HIMACORE

Grading bucket 100cm suitable for CAT 302, 302.5 CR mini excavators

Catalog number:SKX827249HM Nr OEM:BG100-CAT302 Manufacturer:HIMACORE
Add a review

100cm Grading Bucket (G2 Blade) suitable for CAT 302 302.5 - BG100-CAT302

Technical Specification and Compatibility

Professional 1000 mm (100 cm) grading bucket produced by HIMACORE. This attachment has been engineered to fit Caterpillar (CAT) mini excavators of the 302 and 302.5 series, which feature a larger hitch than the 301 series. The bucket features a reinforced G2 steel cutting edge and is ready for immediate use (pin-on or quick hitch compatible).

Part Number: BG100-CAT302
Type: Grading Bucket / Ditching Bucket
Working Width: 1000 mm (100 cm)
Capacity (ISO 7451): 92 Liters
Cutting Edge Material: G2 High Strength Steel
Body Thickness: 5 mm
Hitch Dimensions: 35mm Pins / 135mm Width / 165mm Spacing

HIMACORE is a leader in innovative solutions for construction machinery. Our buckets and attachments are engineered for maximum performance and durability, using certified steel.

Key Features of HIMACORE BG100 Bucket

G2 Blade: The use of G2 grade steel on the cutting edge ensures excellent abrasion resistance during grading and handling loose materials.
Reinforced Hitch: The mounting head is designed to withstand torsional loads typical for wide grading buckets.
Quality Steel: The body made of 5mm plate provides structural rigidity while maintaining low weight, not overloading the mini excavator's hydraulics.
CAT 302 Standard: 165mm pin spacing and 35mm diameter are parameters dedicated to larger CAT mini excavators, ensuring a perfect fit.

Application in machinery

Brand Mini Excavator Models
Caterpillar (CAT) 302, 302.5 (and others with 35mm hitch)

The bucket also fits other machines with identical mounting dimensions (35/135/165 mm).

Related Parts and Hardware

Installation requires two 35 mm diameter pins (not included). We recommend verifying the condition of bushings in the machine arm and link before installing the new bucket.

⚠️ Safety Warning

A 100 cm wide grading bucket generates significant torsional forces on the excavator arm. Avoid digging in hard, rocky ground or prying roots with the bucket corners to prevent damage.

Part Role in the Machine and Failure Diagnostics

The grading bucket is used for finishing work, leveling ground, ditching, and loading loose materials. Its width increases efficiency in light tasks.

  • › Blade wear (loss of straight edge).
  • › Hitch cracks (result of overloading).
  • › Pin hole ovalization (mounting play).
  • › Shell deformation (impacts on hard obstacles).

📞 Can't find the part you're looking for?

No worries. Our website features only a few thousand of the over 60,000 parts we have in stock. Contact us – we likely have what you need readily available!

🔧 Expert Guide: Key Installation Tips

  1. Verify Model: This bucket fits CAT 302/302.5 (35mm pins). It does NOT fit smaller CAT 301 (30mm pins) or larger CAT 303 (40mm pins). Check this!
  2. Lubrication: Generous pin lubrication before assembly and during operation is key to avoiding seizure and squeaking.
  3. Pin Condition: If your old pins have noticeable ridges, replace them. Old pins will quickly destroy the holes in the new bucket.

Frequently Asked Questions (FAQ)

Does it fit CAT 301.8?

Likely not. CAT 301.8 usually uses the 30mm pin standard. This bucket is dedicated to the 302 series with 35mm pins.

Does the bucket have teeth?

No. This is a grading bucket with a smooth edge, designed for leveling ground, not for aggressive digging.

Does it fit a quick hitch?

Yes, if the quick hitch supports the CAT 302 dimensional standard (35/135/165 mm).

Question mark

Do you have doubts or need confirmation to avoid costly downtime? Call us. Our experts will help you select the right part to get your equipment back to work as quickly as possible.

SKX827249HM
BG100-CAT302
68.00 kg

Data sheet

SUITABLE FOR
CAT
MACHINE TYPE
MINIEXCAVATOR
OEM NUMBERS
BG100-CAT302
WIDTH (MM)
1000
PINS (MM)
35
ARM WIDTH (MM)
135
SPACING OF THE PINS (MM)
165

Specific References

MPN
BG100-CAT302
