• Bucket ditching tapered suitable for CASE - COBRA HARDOX
  • Bucket ditching tapered suitable for CASE - COBRA HARDOX
Bucket ditching tapered suitable for CASE - COBRA HARDOX
HIMACORE

Bucket ditching tapered suitable for CASE 580, 590, 695 - COBRA HB400

Catalog number:BDCASE Nr OEM:BDCASE Manufacturer:HIMACORE
Add a review

Trapezoidal Bucket "Cobra" 0.25m3 suitable for CASE 580 590 695 - BDCASE

Technical Specification and Design

Professional trapezoidal bucket (V-ditch bucket) by HIMACORE, Cobra model. Dedicated to CASE backhoe loaders (580, 590, 695 series). The bucket is brand new and complete – equipped with bushings and teeth, ready for immediate installation. Distinguished by the use of a cutting edge made of wear-resistant HB400 steel and an innovative hanger design tailored to the CASE system.

Part Number: BDCASE
Bucket Type: Trapezoidal / V-ditch bucket
Capacity: 0.25 m3 (ISO 7451)
Side Angle: 2x30 degrees
Dimensions (Bottom / H / Top): 46 cm / 100 cm / 147 cm
Cutting Edge Material: HB400 Wear Resistant Steel
Manufacturer: HIMACORE

HIMACORE "Cobra" series offers unmatched stability. The hanger ears are welded into the bottom and a special reinforcing beam. This design prevents the upper part of the bucket from twisting, which is critical for the specific CASE mounting system.

Mounting Dimensions (CASE Standard)

Pin Diameters: 38 mm and 45 mm
Arm Widths: 127 mm and 255 mm
Pin Spacing: 362 mm (center to center)
Compatibility: The dimensions match the standard CASE backhoe arm (distinctive two different pin diameters and widths). The bucket fits both traditional pin mounting and quick couplers. (Pins not included).

Application in machinery

Brand Backhoe Loader Models
CASE 580, 590, 695 (K, L, M, R, SR, ST, SV series)

Cobra Model Special Features

  • › Reinforced Hanger: The CASE mounting system generates significant torsional forces. The Cobra design with an additional beam stiffens the upper part of the bucket, preventing weld cracks.
  • › HB400 Steel: Using abrasion-resistant steel in the ground contact zone significantly extends service life.
  • › Optimal Geometry: V-shape with a 30-degree angle and 46/147 cm proportions allows for fast and precise digging of drainage ditches.

Question mark

Are you unsure about the hanger dimensions on your CASE? Call us. We will check your quick coupler dimensions and help you select the perfect bucket.

BDCASE
BDCASE
175.00 kg

Data sheet

SUITABLE FOR
CASE
MACHINE TYPE
BACKHOE LOADER
OEM NUMBERS
BDCASE
HEIGHT (MM)
700
WIDTH (MM)
400
1300
NUMBER OF TEETH
3
PINS (MM)
38
45
ARM WIDTH (MM)
127
255
SPACING OF THE PINS (MM)
362

Specific References

MPN
BDCASE
