Bucket ditching tapered suitable for JCB 3CX 4CX / MINI EXCAVATORS - COBRA HB400 - 537/16200
HIMACORE

Bucket ditching tapered suitable for JCB 3CX 4CX / MINI EXCAVATORS - COBRA HB400

Catalog number:SKX819233 Nr OEM:537/16200 Manufacturer:HIMACORE
Add a review

HIMACORE COBRA V-BUCKET (TRAPEZOIDAL, HB400, 270L) SUITABLE FOR JCB - 537/16200

Technical Specification and Compatibility

A professional trapezoidal (V-bucket)(Bucket ditching tapered) from the COBRA series, designed for JCB 3CX, 4CX, and large mini excavators (8052-100C). This is a brand new, complete bucket (with bushings and teeth) ready for work. The COBRA model features an innovative, reinforced hitch structure – the ears are welded to both the bottom shell and a special cross-beam, preventing twisting. The elongated bottom profile facilitates digging and prevents material spillage. Ideal for digging and cleaning ditches.

Part number: 537/16200
Manufacturer: HIMACORE (COBRA Series)
Type: Trapezoidal (Ditching Tapered)
Angle: 2 x 30°
Capacity: 270 L (0.25 m³)
Cutting Edge: HB400 Wear Resistant Steel
Dimensions (Bot x Top x H): 400 x 1700 x 700 mm
Hitch Dimensions: Pin diameter 45 mm, Dipper width 175 mm, Pin centers 340 mm

HIMACORE specializes in providing the highest quality hydraulic parts for construction machinery. Our products, such as hydraulic pumps, motors, and valves, are designed for maximum performance and reliability in the toughest working conditions. By choosing HIMACORE, you are investing in the precision, durability, and operational certainty of your machine's hydraulic system.

Essential for Assembly

  • › Mounting pins (45 mm): The bucket does not include pins. They must be purchased separately.

Application in machines

Brand Type / Series / Model
JCB Backhoe Loaders: 3CX, 4CX, 5CX
Mini/Midi Excavators: 8052, 8055, 8060, 8065, 8085, 65R, 67C, 85Z, 86C, 90Z, 100C

The list above is for reference. The 45/175/340 hitch dimensions match the standard JCB 3CX/4CX fitment (pin-on or quickhitch).

⚠️ Safety Warning

Before mounting or dismounting the bucket, ensure the machine is on stable, level ground and the attachment is lowered to the ground. Always use certified lifting slings and ensure no one is in the working area of the attachment.

Part's Role in the Machine and Failure Diagnostics

A trapezoidal bucket is a specialized tool for forming and cleaning ditches, canals, and slopes with a specific angle (here 2x30°). Its technical condition directly impacts the quality and speed of work.

  • › Cracks in welds or plating, especially near the hitch.
  • › Complete wear or bending of the cutting edge (HB400) or teeth.
  • › Ovalization ("egging") of the pin holes, causing play and imprecise work.

📞 Can't find the part you're looking for?

No problem. Our website shows only a few thousand of the over 60,000 parts we have in stock. Contact us – we probably have what you need on the shelf!

🔧 Expert's Guide: Key Installation Tips

  1. Check pins and bushings on the arm: Before mounting the new bucket, check the condition of the pins and bushings on the excavator arm. Any play in these areas will be transferred to the new bucket.
  2. Grease thoroughly: Before installation, generously grease the pins and bushings in the bucket with a suitable grease, such as HYPTRON.
  3. Secure pins correctly: Make sure the pins are properly secured against sliding out, according to the mounting system on your machine.
  4. Check movement: After installation, perform several full cycles of bucket movement to ensure there are no collisions with the arm or cylinder.

Frequently Asked Questions (FAQ)

1. What is the difference between a trapezoidal and a grading bucket?

A grading bucket has a flat bottom and straight sides, used for leveling flat surfaces. A trapezoidal (or V-bucket), like this one, has its bottom and sides fixed at a specific angle (here 30°) to form a V-shape, allowing it to create a perfect trapezoidal ditch profile in a single pass.

2. Will this bucket fit my JCB quickhitch?

Yes. The hitch dimensions (45mm pins, 175mm arm width, 340mm pin centers) are the standard size for JCB 3CX and 4CX backhoe attachments. It will fit both traditional pin-on mounting and the JCB quickhitch.

3. What are the working dimensions?

The dimensions 400x1700x700 mm typically refer to the bottom width (400 mm), the top width (1700 mm or 170 cm), and the depth/height (700 mm).

Znak zapytania

Have doubts or need confirmation to avoid costly downtime? Call us. Our experts will help you choose the right part to get your equipment back to work as soon as possible.

SKX819233
537/16200
96.00 kg

Data sheet

SUITABLE FOR
JCB
MACHINE TYPE
BACKHOE LOADER
MINIEXCAVATOR
OEM NUMBERS
537/16200
HEIGHT (MM)
700
WIDTH (MM)
400
1700
NUMBER OF TEETH
3
PINS (MM)
45
ARM WIDTH (MM)
175
SPACING OF THE PINS (MM)
340

Specific References

MPN
537/16200
Łączna ocena:
0,0
Kupiłeś ten produkt? Napisz recenzję dla innych!
Be the first to write your review !
Opinion:
(0 opinions)

Write a review

Bucket ditching tapered suitable for JCB 3CX 4CX / MINI EXCAVATORS - COBRA HB400

Catalog number: SKX819233
Title for your review*
Your review*
Your name*
Your email*

Manufacturer

  • Serwis Kop Sp. z o.o. Sp. K.
  • Podkarpacka 57A
  • 35-082 Rzeszów
  • Poland
  • [email protected]
  • +48178643100

Responsible person

  • Serwis Kop Sp. z o.o. Sp. K.
  • Podkarpacka 57A
  • 35-082 Rzeszów
  • Poland
  • [email protected]
  • +48178643100
gross price

5,595.27 zł

net price
4549,00 zł
Last pieces Temporarily unavailable
4549,00 zł
net price

5,595.27 zł

gross price
Nie możesz dodać więcej produktów
  • You will receive 455 points, it gives you 182.00 zł
  • Lowest price from 30 days before the discount: 5,595.27 zł
    PRODUCT SPECIFICATION
    SUITABLE FOR
    JCB
    MACHINE TYPE
    BACKHOE LOADER
    MINIEXCAVATOR
    OEM NUMBERS
    537/16200
    HEIGHT (MM)
    700
    WIDTH (MM)
    400
    1700
    NUMBER OF TEETH
    3
    PINS (MM)
    45
    ARM WIDTH (MM)
    175
    SPACING OF THE PINS (MM)
    340
