Grading bucket 180cm suitable for JCB 3CX 4CX / MINI EXCAVATORS - HB400 blade
HIMACORE

Grading bucket 180cm suitable for JCB 3CX 4CX / MINI EXCAVATORS - HB400 blade

Catalog number:SKX819231 Nr OEM:980/86060 Manufacturer:HIMACORE
Add a review

180cm Grading / Ditching Bucket (HB400) suitable for JCB 3CX 4CX - 980/86060

Technical Specification and Compatibility

A brand new, professional 180 cm (1800 mm) wide grading bucket by HIMACORE. Designed for JCB 3CX, 4CX backhoe loaders and larger JCB mini (midi) excavators in the 5-10 ton range. The bucket is supplied complete with bushings installed, ready for work. The universal hitch (dimensions 45/175/340) ensures trouble-free mounting on pins or via a quick hitch.

Part Number: 980/86060
Type: Grading Bucket / Ditching Bucket / Mud Bucket
Width: 1800 mm (180 cm)
Capacity (ISO 7451): 0.28 m³ (280 L)
Cutting Edge Material: HB400 Wear-Resistant Steel
Pin Diameter: 45 mm
Dipper Width: 175 mm
Pin Centers: 340 mm

HIMACORE is a leader in innovative solutions for construction machinery. Our buckets and attachments are engineered for maximum performance and durability. We use only certified steel and advanced welding processes to ensure every HIMACORE product withstands the toughest working conditions, minimizing downtime and maximizing your productivity.

Innovative Features of the HIMACORE 980/86060 Bucket

Internal Reinforcements: A unique rib system prevents the bucket from twisting under uneven loads (e.g., corner snagging).
Extended Bottom Profile: Optimized shape facilitates material loading and prevents spillage during transport, increasing efficiency.
HB400 Cutting Edge: The cutting edge is made from 400 HB wear-resistant steel, ensuring long service life even in sandy soil.
Robust Body: Entire structure made from quality steel, resistant to cracking and deformation.

Application in machinery

Brand Machine Type Models
JCB Backhoe Loaders 3CX, 4CX (standard rear arm)
JCB Midi Excavators (5-10T) 8052, 8055, 8060, 8065, 8085, 65R-1, 67C-1, 85Z-1, 86C-1, 90Z-1, 100C-1

The list above is for reference. It is crucial to verify the hitch dimensions (45/175/340 mm) on your machine.

Related Parts and Hardware

The bucket comes with bushings installed. To mount it, you will need two 45 mm diameter pins (if your old ones are worn). It is also worth checking the condition of the tipping link.

⚠️ Safety Warning

The 180 cm grading bucket is not designed for heavy digging in rocky or compacted ground. Its width generates large torsional forces that could damage a lighter arm structure (compared to digging buckets). Use it as intended: for loose materials and profiling.

Part Role in the Machine and Failure Diagnostics

A grading bucket (ditching bucket) is used for finishing work: leveling ground, forming slopes and ditches, and loading light bulk materials (topsoil, sand, snow). The 180 cm width ensures high efficiency while maintaining good maneuverability.

  • › Excessive cutting edge wear (rounded edge making grading difficult).
  • › Fatigue cracks around the hitch welds (from overloading).
  • › Deformation of the bucket shell (e.g., after hitting a rock).
  • › Play on the pins (worn bushings in the hitch).

📞 Can't find the part you're looking for?

No worries. Our website features only a few thousand of the over 60,000 parts we have in stock. Contact us – we likely have what you need readily available!

🔧 Expert Guide: Key Installation Tips

  1. Check Dimensions: Confirm your arm is 175 mm wide and uses 45 mm pins. This is standard for JCB 3CX/4CX, but verification is always recommended.
  2. New Pins: If your old pins have noticeable ridges or play, replace them with new ones. This will prevent rapid wear of the new bushings.
  3. Greasing: Generously grease the pins and bushings before first use. Regular (daily) greasing of the grading bucket is crucial due to its width and the forces involved.
  4. Motion Test: After installation, ensure the bucket does not collide with the machine arm or cylinders at full range of motion.

Frequently Asked Questions (FAQ)

Is the bucket sold with pins?

No. The bucket is complete with bushings, but pins (45mm) are not part of the set and must be purchased separately if needed.

Does it fit a quick hitch?

Yes. The bucket hitch is made to standard JCB dimensions (45/175/340), so it fits most standard mechanical and hydraulic quick hitches dedicated to these machines.

What is the capacity of this bucket?

The geometric capacity according to ISO 7451 standard is 0.28 m³, or 280 liters.

Question mark

Do you have doubts or need confirmation to avoid costly downtime? Call us. Our experts will help you select the right part to get your equipment back to work as quickly as possible.

SKX819231
980/86060
165.00 kg

Data sheet

SUITABLE FOR
JCB
MACHINE TYPE
BACKHOE LOADER
MINIEXCAVATOR
OEM NUMBERS
980/86060
WIDTH (MM)
1800
PINS (MM)
45
ARM WIDTH (MM)
175
SPACING OF THE PINS (MM)
340

Specific References

MPN
980/86060
Łączna ocena:
0,0
Kupiłeś ten produkt? Napisz recenzję dla innych!
Be the first to write your review !
Opinion:
(0 opinions)

Write a review

Grading bucket 180cm suitable for JCB 3CX 4CX / MINI EXCAVATORS - HB400 blade

Catalog number: SKX819231
Title for your review*
Your review*
Your name*
Your email*

Manufacturer

  • Serwis Kop Sp. z o.o. Sp. K.
  • Podkarpacka 57A
  • 35-082 Rzeszów
  • Poland
  • [email protected]
  • +48178643100

Responsible person

  • Serwis Kop Sp. z o.o. Sp. K.
  • Podkarpacka 57A
  • 35-082 Rzeszów
  • Poland
  • [email protected]
  • +48178643100
gross price

4,303.77 zł

net price
3499,00 zł
Temporarily unavailable
3499,00 zł
net price

4,303.77 zł

gross price
  • You will receive 350 points, it gives you 140.00 zł
  • Lowest price from 30 days before the discount: 4,303.77 zł
    PRODUCT SPECIFICATION
    SUITABLE FOR
    JCB
    MACHINE TYPE
    BACKHOE LOADER
    MINIEXCAVATOR
    OEM NUMBERS
    980/86060
    WIDTH (MM)
    1800
    PINS (MM)
    45
    ARM WIDTH (MM)
    175
    SPACING OF THE PINS (MM)
    340
