Part Number: 2430909
Type: Left Tie Rod
Overall Length: 515 mm
Shaft Diameter: 42 mm
Thread: M28x1.5
Cone Dimensions: 28.20 mm / 32.20 mm
Manufacturer: GOLDEN EAGLE
Product Description
The 2430909 left tie rod is a high-precision, heavy-duty steering component designed for CAT M313 wheeled excavators. It connects the steering cylinder to the left wheel knuckle, transmitting operator input to the wheel and ensuring accurate machine control even in challenging terrain. Its durable construction and quality materials ensure long service life under intensive use.
Role in the Machine
The tie rod is a critical steering system component, responsible for transferring motion and force from the cylinder to the wheel knuckle. Proper function ensures precise steering, safety, and even tire wear.
Signs of Wear / Failure
⚠️ Safety Warning
Wheeled excavators operate on public roads. A broken or detached tie rod can lead to immediate loss of vehicle control and a serious accident. Regularly inspect joints and steering play to ensure safe operation.
GOLDEN EAGLE Tie Rod Benefits
Application in CAT machinery
|
Machine Type
|
Models / Series
|
|
Wheeled Excavators (M300) |
M313 (C, D, -07), M314 (F, -07), M315 (C, D, D2, GC), M316 (C, D, F), M317 (D2), M318 (C, D, F), M319, M320 (F, D2), M323F |
|
Material Handlers (MH) |
MH3022, M318D MH |
Rod dedicated to the left side. CAT wheeled excavators use various axles, so we recommend length verification before purchase
