Hydraulic grading bucket 150cm suitable for JCB 3CX 4CX COBRA HB500

Catalog number:SKX819230 Nr OEM:980/86061 Producer:HIMACORE
Add a review

Hydraulic slope bucket (COBRA model) with a width of 150 CM and increased capacity up to 270L, suitable for JCB 3CX, 4CX backhoe loaders and 8052/8055/8060/8065/8085/67C/65R/67C/85Z/86C/90Z mini excavators /100C - HB500 REINFORCED BLADE

The bucket is brand new, complete, with bushings (the bucket does not include pins) - ready to install and work on a JCB machine.

A special model of a ditching bucket belonging to a separate group of buckets - COBRA BUCKETS, characterized by the highest quality of workmanship and materials used, designed to work in various conditions. Thanks to the unique construction of the shell, special assembly of the ears and crossbeam, the spoon can be used in extremely difficult and demanding conditions. It works very well in clay terrain because thanks to its design, the excavated material does not stick and does not block the bucket. The big advantage of the bucket is its larger capacity compared to buckets of other brands (0.27 m3 270L to 180L, respectively). The increased capacity makes work easier and more efficient, especially with loose material.

The bucket body is made of S355J2G3 quality steel, while the blade is made of HB500 hard-wearing steel.

Bucket capacity: 0.27m3 - 270L
The bucket is made in accordance with the standard: ISO 7451
Bucket handle dimensions: pin diameter 45 mm, arm width 175 mm, pin spacing 340 mm.

All dimensions correspond to the standard dimensions of the arm in the machine, which means that the bucket fits both quick connectors and traditional mounting with pins.

The bucket was made by a leading European manufacturer.

APP TYPE / MODEL
JCB Backhoe loaders 3CX, 4CX, Mini excavators 8052/8055/8060/8065/8085/67C/65R/67C/85Z/86C/90Z/100C

information

If you have any doubts whether the product you have chosen will be suitable for your machine, contact us and we will select the right part and provide practical tips in a few minutes.

SKX819230
980/86061
300.00 kg

Data sheet

SUITABLE FOR
JCB
MACHINE TYPE
BACKHOE LOADER
MINIEXCAVATOR
OEM NUMBERS
980/86061
WIDTH (MM)
1500
PINS (MM)
45
ARM WIDTH (MM)
175
SPACING OF THE PINS (MM)
340

Specific References

MPN
980/86061
Łączna ocena:
0,0
Kupiłeś ten produkt? Napisz recenzję dla innych!
Be the first to write your review !
Opinion:
(0 opinions)

Write a review

Hydraulic grading bucket 150cm suitable for JCB 3CX 4CX COBRA HB500

Catalog number: SKX819230
Title for your review*
Your review*
Your name*
Your email*

Manufacturer Serwis Kop Sp. z o.o. Sp. K. Podkarpacka 57A 35-082 Rzeszów Poland biuro@serwis-kop.pl +48178643100

Responsible person Serwis Kop Sp. z o.o. Sp. K. Podkarpacka 57A 35-082 Rzeszów Poland biuro@serwis-kop.pl +48178643100

gross price

7,378.77 zł

net price
5999,00 zł
Available in large quantity Temporarily unavailable
5999,00 zł
net price

7,378.77 zł

gross price
Nie możesz dodać więcej produktów
  • You will receive 600 points, it gives you 240.00 zł
  • Lowest price from 30 days before the discount: 7,378.77 zł
    PRODUCT SPECIFICATION
    SUITABLE FOR
    JCB
    MACHINE TYPE
    BACKHOE LOADER
    MINIEXCAVATOR
    OEM NUMBERS
    980/86061
    WIDTH (MM)
    1500
    PINS (MM)
    45
    ARM WIDTH (MM)
    175
    SPACING OF THE PINS (MM)
    340
