Fuel filter separator suitable for VOLVO
REDX

Fuel filter separator suitable for VOLVO

Catalog number:SKX978620RX Nr OEM:VOE11110474 Manufacturer:REDX
Add a review

Fuel Filter Separator suitable for Volvo BL71 L150E - VOE11110474

Technical Specification and Compatibility

Fuel filter (water separator) with part number VOE11110474 from the REDX offer. It is a key fuel system component, dedicated to VOLVO construction machinery. Fits a very wide range of equipment, including BL series backhoe loaders, L series wheel loaders, EC crawler excavators, and articulated haulers. This filter performs the function of pre-cleaning fuel and water separation, protecting the engine from failure.

Part Number: VOE11110474
Component Type: Fuel Water Separator
Type: Spin-on
Application: Water and solid contaminant separation
Engines: Volvo D4D, D5D, D6D, D7D, D12D and others
Manufacturer: REDX

REDX filters use multi-layer filter media that effectively coalesces water, allowing it to settle at the bottom of the filter. This prevents corrosion and seizure of precision Volvo injection system components.

Features of REDX VOE11110474 Filter

Effective Water Separation: Protects the engine from water in fuel, which is the main cause of damage to Common Rail injectors and unit pumps.
High Throughput: The filter design ensures free fuel flow even under heavy engine load, preventing power loss.
Durable Housing: Corrosion and mechanical damage resistant metal canister guarantees tightness in difficult working conditions.
Easy Service: Standard thread and the possibility of mounting a bottom sediment bowl (if present in the machine) facilitate daily maintenance.

Application in VOLVO machinery

Category Models
Backhoe Loaders BL60, BL60B, BL61, BL61 PLUS, BL61B, BL70, BL70B, BL71, BL71 PLUS, BL71B
Wheel Loaders L45F, L50E, L50F, L60E, L70E, L90D, L90E, L110E, L120D, L120E, L150C, L150D, L150E, L180C, L180D, L180DHL, L180E, L180EHL, L220D, L220E, L330E
Crawler Excavators EC140B LC, EC160B, EC180B, EC210B, EC240B, EC240B FX, EC290B, EC290B FX, EC360B
Wheeled Excavators EW145B, EW160B, EW180B
Articulated Haulers A25D, A30D, A35D, A40D
Graders and Compactors G710B, G930, SD110, SD110B, PT220
Asphalt Pavers P4370B, P5320B

Filter fits Volvo B, C, D, and E series machines. Check the number on the old filter before purchasing.

Related Parts and Hardware

Filter 11110474 is a water separator (primary). Usually, it has an opening at the bottom for a water sensor or drain plug (often transferred from the old filter). When servicing, it is worth replacing the fine fuel filter as well.

⚠️ Operational Warning

The illumination of the "water in fuel" light on the dashboard means the separator must be drained immediately. Driving with water in the fuel system leads to irreversible damage to the injection pump and injectors.

Part Role in the Machine and Failure Diagnostics

Filter VOE11110474 is the first barrier for contaminants from the tank.

  • › Starting difficulties (air in system or blockage in filter).
  • › Power loss under load (clogged cartridge).
  • › Water in fuel alarm (sediment bowl drainage needed).
  • › Uneven engine running (fuel supply interruption).

📞 Can't find the part you're looking for?

No worries. Our website features only a few thousand of the over 60,000 parts we have in stock. Contact us – we likely have what you need readily available!

🔧 Expert Guide: Key Installation Tips

  1. Part Transfer: The new filter is often supplied without the bottom plug/water sensor. Remember to transfer this element from the old filter, replacing the gasket (O-ring) in the process.
  2. Gasket Lubrication: Always lubricate the top filter gasket with clean diesel fuel before tightening. This prevents damage and facilitates later removal.
  3. Bleeding: After replacing the filter, use the hand pump (on the filter head) to fill the system with fuel and remove air.

Technical FAQ and Trivia

Is this a fine filter?

No, VOE11110474 is a water separator, i.e., a pre-filter. Its main task is to separate water and stop larger particles. The fine filter (usually smaller) is located further in the system.

Does it fit Deutz engines in Volvo?

Yes, many Volvo engines from that period (designations D4D, D5D, D6D, D7D) were based on Deutz designs (series 2012/2013) and use the same filter standard.

Trivia about Volvo BL71

The Volvo BL71 backhoe loader was one of the first machines of this type designed from scratch by Volvo (after acquiring the Samsung construction machinery division). It is famous for its very durable D4D engine, which requires such high-quality water separators for trouble-free operation.

Question mark

Do you have doubts or need confirmation to avoid costly downtime? Call us. Our experts will help you select the right part to get your equipment back to work as quickly as possible.

SKX978620RX
VOE11110474
0.00 kg

Data sheet

SUITABLE FOR
VOLVO
MACHINE TYPE
BACKHOE LOADER
OEM NUMBERS
VOE11110474 / 11110474 / VOE11110668 / 11110668 / P505957 / P 50-5957 / SN 912210 / SN912210
ENGINE
DEUTZ
OUTER DIAMETER (MM)
108,6
INNER DIAMETER (MM)
24
HEIGHT (MM)
220

Specific References

MPN
VOE11110474
Łączna ocena:
0,0
Kupiłeś ten produkt? Napisz recenzję dla innych!
Be the first to write your review !
Opinion:
(0 opinions)

Write a review

Fuel filter separator suitable for VOLVO

Catalog number: SKX978620RX
Title for your review*
Your review*
Your name*
Your email*

Manufacturer

  • Serwis Kop Sp. z o.o. Sp. K.
  • Podkarpacka 57A
  • 35-082 Rzeszów
  • Poland
  • [email protected]
  • +48178643100

Responsible person

  • Serwis Kop Sp. z o.o. Sp. K.
  • Podkarpacka 57A
  • 35-082 Rzeszów
  • Poland
  • [email protected]
  • +48178643100
gross price

65.19 zł

net price
53,00 zł
Available in large quantity Temporarily unavailable
53,00 zł
net price

65.19 zł

gross price
Nie możesz dodać więcej produktów
  • You will receive 5 points, it gives you 2.00 zł
  • Place an order within 03h 17m 59s And we will send your order today

    Lowest price from 30 days before the discount: 65.19 zł
    PRODUCT SPECIFICATION
    SUITABLE FOR
    VOLVO
    MACHINE TYPE
    BACKHOE LOADER
    OEM NUMBERS
    VOE11110474 / 11110474 / VOE11110668 / 11110668 / P505957 / P 50-5957 / SN 912210 / SN912210
    ENGINE
    DEUTZ
    OUTER DIAMETER (MM)
    108,6
    INNER DIAMETER (MM)
    24
    HEIGHT (MM)
    220
