Fuel sediment water suitable for JCB 3CX 4CX - FOR WINTER
JCB

Fuel sediment water suitable for JCB 3CX 4CX - FOR WINTER

Catalog number:32/925705D Nr OEM:32/925705 Manufacturer:JCB
Add a review

Fuel filter – water separator 150 µm suitable for JCB 2CX / 3CX / 4CX / RTFL / Loadall – 32/925705

Technical Specifications & Compatibility

Genuine winter-grade fuel pre-filter and water separator (150 µm). Traps water and coarse debris upstream of the fine filter to improve cold-weather starting and reliability.

Part number: 32/925705
Alternate notations: 32-925705, 32925705
Type: Spin-on fuel water separator, winter grade 150 µm
Outer dimensions: height ~135.5 mm; OD ~83.5 mm

Genuine JCB component — factory match to JCB fuel systems.

Machine Applications

Brand (Machine type) Model
JCB (Backhoe loaders) 2CX, 3CX, 4CX (various engine/fuel system versions)
JCB (Telehandlers) Loadall — selected models equipped with 150 µm separator
JCB (Forklifts) RTFL — Rough Terrain Forklift (selected versions)

Indicative list. Confirm 32/925705 and dimensions against the fitted unit in your machine.

Functions & Benefits

  • Removes free water and coarse debris upstream of the fine filter.
  • 150 µm winter grade — reduces cold-weather fuel starvation.
  • Quick spin-on service for minimal downtime.
  • Extends life of injectors and the main fuel filter.
  • Compatible with JCB original filter heads.

🔧 Expert Guide: Key Installation Tips

1. Clean the head

Thoroughly clean the area to prevent dirt ingress.

2. Oil the gasket

Lightly oil the seal; hand-tighten ~3/4 turn after contact.

3. Prime and leak-check

Use the primer/bleeding procedure; start the engine and verify tightness.

4. Swap seasonally

Use 150 µm in winter; return to standard micron rating after the season per JCB guidance.

⚠️ Safety Warning

Do not run with a bypassed separator or a leaking seal — water ingress can damage injectors and pumps.

Role in the Machine & Failure Diagnostics

The separator shields the fine filter and injection system from water/paraffins. Wrong micron rating or worn media increases stall and failure risk.

  • Hard starting in frost, stalling after start.
  • Low fuel pressure warnings, power loss.
  • Visible water/sediment in the bowl (if fitted).
  • Wet housing or seal — potential air ingress.

Peace of Mind: Why Choose SERWIS-KOP?

Don’t let contaminated fuel halt your work — winter-proof your machine now.

Part 32/925705 is in stock. We’ll match the correct filter to your configuration and dispatch quickly.

📞 Not seeing your exact variant?

We show only a fraction of our range — 60,000+ parts available. Call us and we’ll confirm and ship same-day when possible.

Related Items

  • › Main/fine fuel filter (winter ↔ summer) — swap seasonally per JCB guidance.
  • › Head seals / O-rings — replace at each service.
  • › REDX funnels & pre-filters — reduce contamination during refuelling.

Frequently Asked Questions (FAQ)

1. What’s the difference between 150 µm separator and the main filter?

The separator is a winter pre-filter — it passes fine fractions while trapping water and coarse debris to protect the fine filter.

2. When should I use 150 µm?

During cold seasons with paraffin risk. Return to the standard micron rating after winter.

3. Do I need to bleed the system after replacement?

Yes — prime the system, start, and leak-check.

Question mark

Need help choosing? Call: +48 17 864 31 00 — we’ll match the correct filter and ship fast.

JCB
32/925705D
32/925705
0.21 kg

Data sheet

SUITABLE FOR
JCB
MACHINE TYPE
BACKHOE LOADER
FORKLIFT
TELESCOPIC HANDLER
OEM NUMBERS
32/925705
ENGINE
JCB DIESELMAX
OUTER DIAMETER (MM)
83,5
HEIGHT (MM)
135,5

Specific References

MPN
32/925705
Łączna ocena:
0,0
Kupiłeś ten produkt? Napisz recenzję dla innych!
Be the first to write your review !
Opinion:
(0 opinions)

Write a review

Fuel sediment water suitable for JCB 3CX 4CX - FOR WINTER

Catalog number: 32/925705D
Title for your review*
Your review*
Your name*
Your email*

Manufacturer

  • Serwis Kop Sp. z o.o. Sp. K.
  • Podkarpacka 57A
  • 35-082 Rzeszów
  • Poland
  • [email protected]
  • +48178643100

Responsible person

  • Serwis Kop Sp. z o.o. Sp. K.
  • Podkarpacka 57A
  • 35-082 Rzeszów
  • Poland
  • [email protected]
  • +48178643100
gross price

236.78 zł

net price
192,50 zł
Available in large quantity Temporarily unavailable
192,50 zł
net price

236.78 zł

gross price
Nie możesz dodać więcej produktów
  • You will receive 19 points, it gives you 7.60 zł
  • Lowest price from 30 days before the discount: 236.78 zł
    PRODUCT SPECIFICATION
    SUITABLE FOR
    JCB
    MACHINE TYPE
    BACKHOE LOADER
    FORKLIFT
    TELESCOPIC HANDLER
    OEM NUMBERS
    32/925705
    ENGINE
    JCB DIESELMAX
    OUTER DIAMETER (MM)
    83,5
    HEIGHT (MM)
    135,5
