Hydraulic grading bucket 150cm suitable for CAT 428D 428E 428F 432E - COBRA
NEXGEN

Hydraulic grading bucket 150cm suitable for CAT 428D 428E 428F 432E - COBRA

Catalog number:BGH150CATDEF Nr OEM:BGH150CATDEF Manufacturer:NEXGEN
Add a review

NEXGEN 150CM HYDRAULIC GRADING BUCKET (TILTING, HB400, COBRA) SUITABLE FOR CAT 428D-F - BGH150CATDEF

Technical Specification and Compatibility

A brand new, complete 150 cm hydraulic tilting grading bucket from the reinforced COBRA BUCKETS series by NEXGEN. Designed for CATERPILLAR 428D, 428E, 428F, 432E, 438, 442, and 444 backhoe loaders. The hydraulic cylinder allows for precise angled grading without repositioning the machine. It features an innovative reinforced hitch structure (ears welded to the bottom and a special cross-beam) to prevent twisting, and an elongated bottom profile for easier handling of loose or sticky materials. The body is S355 steel, and the cutting edge is HB400 wear-resistant steel. ISO 7451 compliant and ready to mount (pins not included).

Part number: BGH150CATDEF
Type: Hydraulic Grading / Tilting Bucket
Series: COBRA (Reinforced)
Width: 1500 mm
Capacity: 270 L (0.27 m³)
Cutting Edge: HB400 Wear Resistant Steel
Body: S355J2G3 Quality Steel
Dimensions (Bot x Top x H): 460 x 1470 x 1000 mm
Hitch Dimensions: Pin diameters 45 mm and 50 mm, dipper width 205 mm and 255 mm, pin centers 345 mm

In the construction industry, machine reliability is the key to success. That's why we offer high-quality replacement parts for construction machinery that meet the highest standards of durability and performance. Our products are the ideal solution for companies and specialists looking for reliable components at attractive prices.

Essential for Assembly

  • › Mounting pins (45 mm and 50 mm): The bucket does not include pins. They must be purchased separately.
  • › Hydraulic Hoses: Required to connect the bucket's cylinder to the machine's auxiliary hydraulic line.

Application in machines

Brand Type / Series / Model
CATERPILLAR Backhoe Loaders: 428D, 428E, 428F, 432E, 438, 442, 444

The list above is for reference. You must verify your dipper arm dimensions: 45mm & 50mm pin diameters, 205mm & 255mm arm widths, and 345mm pin centers.

⚠️ Safety Warning

Before mounting or dismounting the bucket, ensure the machine is on stable, level ground and the attachment is lowered to the ground. Release pressure from the hydraulic system before connecting hoses. Always use certified lifting slings and ensure no one is in the working area.

Part's Role in the Machine and Failure Diagnostics

A hydraulic tilting bucket is a specialized tool for precise terrain profiling, ditch cleaning, and finishing slopes at an angle, without repositioning the machine. Its technical condition directly impacts the quality and speed of work.

  • › Leaks from the hydraulic cylinder (failed seals).
  • › Cracks in welds or plating (especially near the hitch and reinforcements).
  • › Complete wear of the cutting edge (HB400) and teeth.
  • › Ovalization ("egging") of the pin holes, causing play.

📞 Can't find the part you're looking for?

No problem. Our website shows only a few thousand of the over 60,000 parts we have in stock. Contact us – we probably have what you need on the shelf!

🔧 Expert's Guide: Key Installation Tips

  1. Check pins and bushings on the arm: Before mounting the new bucket, check the condition of the pins and bushings on the excavator arm. Any play in these areas will be transferred to the new bucket.
  2. Grease thoroughly: Before installation, generously grease the pins (45mm and 50mm), bushings, and cylinder pins with a suitable grease, such as HYPTRON.
  3. Clean Couplers: Before connecting the hydraulic hoses, ensure the couplers on the machine and hoses are perfectly clean.
  4. Bleed the System: After installation, perform several full tilt cycles (left and right) to bleed the air from the cylinder and check for leaks.

Frequently Asked Questions (FAQ)

1. What is the difference between this and a standard ditching bucket?

This bucket is hydraulic (tilting). It has a built-in hydraulic cylinder that allows the operator to tilt the bucket sideways (left/right), which is essential for precise grading of slopes at an angle without repositioning the machine.

2. Why does this hitch have two different pin diameters (45mm and 50mm)?

This is a specific design feature of the hitch system used on CATERPILLAR 428D, E, F and newer backhoe loaders. Unlike systems with two identical pins, the CAT hitch uses different diameters and widths for the dipper pin and the link pin.

3. Will this bucket fit a CAT 428C or a JCB 3CX?

Absolutely not. This bucket is exclusively for CAT D/E/F-series machines with the 345mm pin center hitch. The older 428B/C models used a 370mm pin center. The JCB system (45/175/340) is completely different. None of these systems are compatible.

Znak zapytania

Have doubts or need confirmation to avoid costly downtime? Call us. Our experts will help you choose the right part to get your equipment back to work as soon as possible.

BGH150CATDEF
BGH150CATDEF
300.00 kg

Data sheet

SUITABLE FOR
CAT
MACHINE TYPE
BACKHOE LOADER
OEM NUMBERS
BGH150CATDEF
WIDTH (MM)
1500
PINS (MM)
45
50
ARM WIDTH (MM)
205
255
SPACING OF THE PINS (MM)
345

Specific References

MPN
BGH150CATDEF
Łączna ocena:
0,0
Kupiłeś ten produkt? Napisz recenzję dla innych!
Be the first to write your review !
Opinion:
(0 opinions)

Write a review

Hydraulic grading bucket 150cm suitable for CAT 428D 428E 428F 432E - COBRA

Catalog number: BGH150CATDEF
Title for your review*
Your review*
Your name*
Your email*

Manufacturer

  • Serwis Kop Sp. z o.o. Sp. K.
  • Podkarpacka 57a
  • 35-082 Rzeszów
  • Poland
  • [email protected]
  • +48178643100

Responsible person

  • Serwis Kop Sp. z o.o. Sp. K.
  • Podkarpacka 57A
  • 35-082 Rzeszów
  • Poland
  • [email protected]
  • +48178643100
gross price

7,378.77 zł

net price
5999,00 zł
Last pieces Temporarily unavailable
5999,00 zł
net price

7,378.77 zł

gross price
Nie możesz dodać więcej produktów
  • You will receive 600 points, it gives you 240.00 zł
  • Lowest price from 30 days before the discount: 7,378.77 zł
    PRODUCT SPECIFICATION
    SUITABLE FOR
    CAT
    MACHINE TYPE
    BACKHOE LOADER
    OEM NUMBERS
    BGH150CATDEF
    WIDTH (MM)
    1500
    PINS (MM)
    45
    50
    ARM WIDTH (MM)
    205
    255
    SPACING OF THE PINS (MM)
    345
